CA-B/A系列普通车床
| CA6140B/A | CA6240B/A | CA6150B/A | CA6250B/A | CA6161B/A | CA6261B/A | ||
| 床身上回转直径 | mm | φ400(16") | φ400(16") | φ500(20") | φ500(20") | φ610(24") | φ610(24") |
| 刀架上回转直径 | mm | φ210 (8 1/4") |
φ210 (8 1/4") |
φ300 (12") |
φ300 (12") |
φ370 (14 9/16 ") |
φ370 (14 9/16 ") |
| 马鞍内回转直径× 有效宽度 |
mm | φ630(25") ×210 |
φ720(28") ×210 |
φ830 (32 2/3 ") ×210 |
|||
| 二顶尖间长度 | mm | 750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
750/1000/ 1500/2000/ 3000 (29"/40"/ 60"/118") |
| 床身宽度、硬度 | mm | 400、RC52 | 400、RC52 | 400、RC52 | 400、RC52 | 400、RC52 | 400、RC52 |
| 刀杆截面 | mm | 25×25 | 25×25 | 25×25 | 25×25 | 25×25 | 25×25 |
| 主轴 | |||||||
| 主轴转速范围(级数) | |||||||
| 正传 | r/min | 10-1400 (24 kinds) |
10-1400 (24 kinds) |
10-1400 (24 kinds) |
10-1400 (24 kinds) |
10-1400 (24 kinds) |
10-1400 (24 kinds) |
| 反转 | r/min | 14-1580 (12 kinds) |
14-1580 (12 kinds) |
14-1580 (12 kinds) |
14-1580 (12 kinds) |
14-1580 (12 kinds) |
14-1580 (12 kinds) |
| 主轴内孔直径 | mm | φ80 (3 9/64") |
φ80 (3 9/64") |
φ80 (3 9/64") |
φ80 (3 9/64") |
φ80 (3 9/64") |
φ80 (3 9/64") |
| 主轴头型式 | mm | A28 | A28 | A28 | A28 | A28 | A28 |
| 前主轴孔锥度 | φ90(1:20) | φ90(1:20) | φ90(1:20) | φ90(1:20) | φ90(1:20) | φ90(1:20) | |
| 进给 | |||||||
| 进给数量 | 64 kinds (for each) |
64 kinds (for each) |
64 kinds (for each) |
64 kinds (for each) |
64 kinds (for each) |
64 kinds (for each) |
|
| 主轴每转纵向进给 | |||||||
| 标准 | mm/r | 0.11-1.6 | 0.11-1.6 | 0.11-1.6 | 0.11-1.6 | 0.11-1.6 | 0.11-1.6 |
| 小进给 | mm/r | 0.028-0.11 | 0.028-0.11 | 0.028-0.11 | 0.028-0.11 | 0.028-0.11 | 0.028-0.11 |
| 加大进给 | mm/r | 1.76-6.4 | 1.76-6.4 | 1.76-6.4 | 1.76-6.4 | 1.76-6.4 | 1.76-6.4 |
| 主轴每转横向进给 | |||||||
| 标准 | mm/r | 0.05-0.8 | 0.05-0.8 | 0.05-0.8 | 0.05-0.8 | 0.05-0.8 | 0.05-0.8 |
| 小进给 | mm/r | 0.014-0.05 | 0.014-0.05 | 0.014-0.05 | 0.014-0.05 | 0.014-0.05 | 0.014-0.05 |
| 加大进给 | mm/r | 0.88-3.2 | 0.88-3.2 | 0.88-3.2 | 0.88-3.2 | 0.88-3.2 | 0.88-3.2 |
| 公制螺纹范围 | mm | 1-192 (44 kinds) |
1-192 (44 kinds) |
1-192 (44 kinds) |
1-192 (44 kinds) |
1-192 (44 kinds) |
1-192 (44 kinds) |
| 英制螺纹范围 | t.p.i | 1/2-24 (28kinds) |
1/2-24 (28kinds) |
1/2-24 (28kinds) |
1/2-24 (28kinds) |
1/2-24 (28kinds) |
1/2-24 (28kinds) |
| 模数螺纹范围 | mm | 0.25-48(module) (39 kinds) |
0.25-48(module) (39 kinds) |
0.25-48(module) (39 kinds) |
0.25-48(module) (39 kinds) |
0.25-48(module) (39 kinds) |
0.25-48(module) (39 kinds) |
| 径节螺纹范围 | D.P | 1/2-96 (38 kinds) |
1/2-96 (38 kinds) |
1/2-96 (38 kinds) |
1/2-96 (38 kinds) |
